Low Hazard Heat Shrink Insulation Tube 100mm Low Smoke Cable Identification Sleeve
| Place of Origin | China |
|---|---|
| Brand Name | Long |
| Certification | ISO |
| Model Number | 20.1 |
| Minimum Order Quantity | 1piece |
| Price | 0.05 |
| Packaging Details | Roll/Carton |
| Delivery Time | 1-9days |
| Payment Terms | T/T, D/P, D/A, L/C, Western Union, MoneyGram |
| Supply Ability | 400000meters per day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| MOQ | 1piece | Colour | Yellow |
|---|---|---|---|
| Operating Temperature Range | -55~+120°C | Minimum Recovery Temperature | 110°C |
| Maximum Storage Temperature | 40°C | Shrink Ratio | 2:1 |
| Printing Mode | Single Sided Printing And Double Sided Printing Formats Available | Supplied Mode Recommended Printers | Recommended Ribbons |
| Highlight | long low hazard heat shrink insulation tube,low hazard heat shrink insulation tube long,Low Smoke Cable Identification Sleeves |
||
Product Description
Black Halogen Free Low Smoke Low Hazard Identification Sleeves
Halogen Free Low Smoke Low Hazard Identification Sleeves
Description: HNF marker sleeve is a flattened, heat-shrinkable tubing designed for wire and cable harness identification. It can also be used for applications where limited fire hazard characteristics are necessary. The zero halogen material coupled with low smoke and low toxic fume emissions make this product perfectly used in enclosed spaces such as mass transit, marine and industrial installations.
Standard : NF F16-101, DIN5510-2, BS6853, EN45545-2, SAE-AS 81531, MIL-STD- 202F/Method 215J, RoHS .FPA130.
Features
Material | The sleeving shall be fabricated from irradiated, thermally stabilized and flame retarded modified polyolefin compound containing no halogens or cadmium in the formulation. |
| Operating temperature range | -55~+125°C |
| Minimum recovery temperature | +115°C |
| Maximum storage temperature | +40°C |
| Shrink ratio | 2:1 |
| Color | White, Yellow, other color is available if ordered |
| Printing mode | Single sided printing and Double sided printing formats available |
Supplied mode | Either Continuous type or Ladder format type is available Thermal transfer printer |
| Recommended Ribbons | N85 resin ribbon, Black, 100mm(width)*300m(length) |
Dimensions
| Part Number | As Supplied (mm) | After Recovery(mm) | |||
ID (D) | Flatten Width (W) | Double Wall Thickness | ID (d) | Single Wall Thickness | |
| HNF-M-2X-2.4- | 2.79±0.20 | 5.0±0.3 | 0.48±0.10 | W1.18 | 0.49±0.06 |
| HNF-M-2X-3.2- | 3.64±0.23 | 6.3±0.4 | 0.48±0.10 | <1.59 | 0.51±0.06 |
| HNF-M-2X-4.8- | 5.26±0.25 | 8.9±0.4 | 0.49±0.10 | W2.36 | 0.54±0.06 |
| HNF-M-2X-6.4- | 6.92±0.28 | 11.5±0.4 | 0.50±0.10 | W3.18 | 0.56±0.06 |
| HNF-M-2X-9.5- | 10.2±0.32 | 16.7±0.5 | 0.51±0.11 | W4.75 | 0.59±0.06 |
| HNF-M-2X-12.7- | 13.5±0.36 | 21.8±0.6 | 0.52±0.11 | W6.35 | 0.60±0.07 |
| HNF-M-2X-19- | 20.1±0.40 | 32.2±0.6 | 0.53±0.11 | <9.53 | 0.62±0.07 |
| HNF-M-2X-25- | 26.7±0.45 | 42.5±0.7 | 0.55±0.12 | <12.7 | 0.63±0.07 |
| HNF-M-2X-38- | 39.8±0.51 | 63.2±0.8 | 0.57±0.12 | W19.1 | 0.64±0.07 |
Package Information
| Ordering Size (HNF-M-2X) | Ladder Format Type | Continuous Type | |
| A&B-Small Box Packing (PCS/Box) | A-Paper reel Packing (m/reel) | B-Plastic reel Packing (m/reel) | |
| 0)2.4 | 2500 | 50 | 25 |
| 023.2 | 2000 | 100 | 25 |
| (P4.8 | 2000 | 100 | 25 |
| (P6.4 | 2000 | 100 | 25 |
| (P9.5 | 1000 | 100 | 25 |
| 012.7 | 1000 | 100 | 25 |
| 019 | 500 | 100 | 25 |
| 025 | 500 | 100 | 25 |
| 038 | 500 | 50 | 25 |
