20mm Single Wall Heat Shrink Tubing 25mm Flame Retardant , V0 Orange Shrink Tube

  • 20mm Single Wall Heat Shrink Tubing 25mm Flame Retardant , V0 Orange Shrink Tube
  • 20mm Single Wall Heat Shrink Tubing 25mm Flame Retardant , V0 Orange Shrink Tube
Place of Origin China
Brand Name Long
Certification ISO
Model Number 20-25mm
Minimum Order Quantity 1m
Price 0.05
Packaging Details Roll/Carton
Delivery Time 1-9days
Payment Terms T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability 400000meters per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Retardant V0 Flame Retardant Color New Energy Orange
Wall Thickness 0.7mm Shrink Ratio 2:1
Good Resistance To Common Fluids And Solvents Certificate UL Approved
Continuous Operating Temperature -55°C ~150°C Compliant RoHS Compliant
Highlight

long v0 orange shrink tube

,

v0 orange shrink tube long

,

V0 Orange Shrink Tubes
Leave a Message
Product Description

New Energy Orange 20mm 25mm V0 Flame Retardant 2X Hea Shrink Tubing





150°c Flame retardant heat shrink tubing





Features





•  2:1 shrink ratio

•  Flame retardant

•  Good resistance to common fluids and solvents

•  UL approved

•  Continuous operating temperature:-55°C ~150°C

•  Fully shrink temperature:135°C

•  RoHS compliant



Dimensions



Size As Supplied After Recovery Standard Package
Inch mm Internal Diameter mm Internal Diameter mm Wall Thickness mm Spool Lenqth M/spooF
3/64 1.0 N1.20 W0.60 0.41±0.10 200
1/16 1.5 5=1.60 W0.80 0.43±0.10 200
3/32 2.5 N2.40 W1.20 0.51±0.10 200
1/8 3.0 N3.20 ^1.60 0.5110.10 200
3/16 4.5 ^4.80 <2.40 0.51±0.10 100
1/4 6.0 N6.4. W3.20 0.64±0.10 100
3/8 9.0 N9.50 W4.80 0.64±0.10 100
1/2 12 5=12.7 <6.40 0.64±0.10 100
3/4 18 N19.1 W9.50 0.76±0.15 100
1 25 N25.4 W12.7 0.89±0.15 50
5/4 32 N32 W15.9 0.8910.15 50
3/2 38 N38 W19.1 1.00±0.15 50
2 50 N51 <25.4 1.15±0.15 25
3 75 N76 W38.1 1.27±0.20 25
4 100 N102 W50.8 1.40±0.20 25
5 120 >125 W63.5 1.40±0.25 25





Technical Data

I Property Test Method Typical Performance I
Tensile strength(MPa) ASTM D2671 5=10.4
Ultimate elongation(%) ASTM D2671 >200
Tensile strength after heat aged(Mpa) 180°CX168h N7.3
Ultimate elongation after heat aged (%) 180°CX168h >100
Corrosion UI224 Pass
Flammability ASTM D 2671C method VW-1
Voltage withstand 2500V, 60s No breakdown
Heat shock(%) 250°CX4h No cracks, flowing or dripping
Cold blend -30°CX1 h No cracks
Dielectric strength (kv/mm) ASTM D 149 N15
Volume resistivity (Q-cm) ASTM D 876 ^1014
Water absorption(%) UL224 <0.5
